Rahmen KELLYS Alutec RRC 29" - Race Ready Concept, 1.5" tapered HT
Gabel SR SUNTOUR XCM32 NLO DS (29"), 100 mm, coil / Speed Lockout
Kurbelgarnitur SHIMANO Cues U4000-1 (32T) - length 170 mm (S), 175 mm (M - XL)
Schaltwerk SHIMANO Cues U4000 (direct mount)
Schalthebel SHIMANO Cues SL-U4010-9R Rapidfire Plus
Gänge 9
Kassetenzahnkranz SHIMANO Linkglide CS-LG300-9 (11-46T)
Kette SHIMANO Linkglide CN-LG500
Bremsen SHIMANO MT200 Hydraulic Disc
Bremshebel SHIMANO BL-MT200
Bremsscheiben 160 mm front / 160 mm rear
Naben SHIMANO QC300 Disc Center Lock (32 holes)
Felgen KLS Draft 23 Disc 622x23 (32 holes)
Speichen steel
Reifen WTB Ranger Comp 55-622 (29"x2.25)
Steuersatz 1.5" semi-integrated
Innenlager cartridge (122.5 mm)
Vorbau KLS Active - diam 28.6 mm / bar bore 31.8 mm / length 60 mm (S - M), 70 mm (L - XL)
Lenker KLS Active FlatBar - diam 31.8 mm / width 680 mm (S), 720 mm (M - XL)
Griffe KLS Advancer 2Density
Sattelstütze KLS Active - diam 30.9 mm / length 350 mm (S), 400 mm (M - XL)
Sattel KLS Sentinel 2
Pedale plastic
Rahmengrössen S / M / L / XL
